Ceramic Fiber Insulation Blanket Industrial Thermal Insulation Material

Name: Ceramic Fiber Insulation Blanket Industrial Thermal Insulation Material
Brand: WeiHang
SKU: WeiHang
Price: 1.00 USD
Availability: InStock
Rating: 4.5 (174 reviews)

Large Image : Ceramic Fiber Insulation Blanket Industrial Thermal Insulation Material

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	WeiHang

Payment & Shipping Terms:

Minimum Order Quantity:	1 Roll
Price:	negotiation
Packaging Details:	Plastic bags inside,carton outside
Payment Terms:	L/C, T/T

Contact Now

Detailed Product Description

Raw Material::	Ceramic Fiber Spun Bulk	Item::	128kg/m3 Density Insulation Ceramic Fiber Blanket
Color::	Pure White	Application::	Liners Of Industrial Furnace
Length::	3600-14640mm	Package::	Plastic Bags Inside,carton Outside
Chemical Composition:	Al2O3+SiO2≥99%
High Light:	ceramic fiber wool insulation , refractory ceramic fibres

Industrial Thermal Insulation Material Ceramic Fiber Insulation

Product Description

Ceramic fibre paper is made of selected aluminium silicate ceramic fibre cotton as the main raw material by wet forming process. Based on the traditional process, slag removal and drying process are improved. Its characteristics are asbestos-free, uniform fiber distribution, white color, non-stratification, less slag ball (four centrifugal slag removal), flexible adjustment of bulk density according to use, high strength (including reinforced fibers), good elasticity and strong machinability. Similarly, it can be divided into four kinds of material, standard, high aluminium, zirconium-containing ceramic fiber paper.

It also named aluminum silicate fiber blanket, because their main component is aluminum.

It's a new type of fire-resisting and heat-insulating materials with white color and accurate dimension.

This product does not contain any adhesive to ensure their good stability in high temperature or low temperature environment.

Ceramic heat insulation blanket is completely inorganic and is needled to provide exceptional handling strength, Used in a variety of heat processing applications and is available in a variety of densities, thicknesses, widths and temperature rating.

Ceramic fiber blanket Features and advantage

Fire protection: The shape and size of the fire remain intact after burning.
High temperature resistance: The temperature resistance is 1260 and 1400 C.
Insulation: It can effectively prevent or slow down heat transfer, and the thermal conductivity can be as low as 0.12w/(m.k) at 800 C.
Insulation: Inorganic silicate material, high temperature non-conductive.
Sound insulation: high noise reduction coefficient.
Sealing: It has certain elasticity and can be used for high temperature sealing.
Fire protection: The shape and size of the fire remain intact after burning.
High temperature resistance: The temperature resistance is 1260 and 1400 C.
Insulation: It can effectively prevent or slow down heat transfer, and the thermal conductivity can be as low as 0.12w/(m.k) at 800 C.
Insulation: Inorganic silicate material, high temperature non-conductive.
Sound insulation: high noise reduction coefficient.
Sealing: It has certain elasticity and can be used for high temperature sealing.

Ceramic Fiber Insulation Blanket Industrial Thermal Insulation Material 0

Typical Application

Item		Unit	Aluminum Silicate Fiber Felt	High alumina aluminum silicate fiber felt	Needle punched aluminum silicate blanket	Zirconium-containing aluminum silicate fiber felt	Aluminum silicate fiber brick	Aluminum silicate fiber rope
Chemical composition	Al2O₃	%	46	>60		>38	>46	>46
	SiO₂	%	<50	<38		<1.0(ZrO2)	52	52
	Fe₂O₃	%	<1.2	<1.0		<1.0	1.2	1.2
Fiber diameter		μm	1-4	1-4	2-4	-	1-4	-
Density		Kg/m³	≥150	≥200	≥90	≥95	≥300	≥450
Slag ball content(>0.22mm)		%	<4	<4	-	<10	<5	<5
Thermal Conductivity		W/m.k	<0.045	<0.045	<0.038	<0.055	<0.068	<0.068
Maximum use temperature			1100		1200	1250

Typical Application

Cloth

Insulation materials for high temperature tube and container; the shield for heat radiation, dress for protection of labor, high-temperature safety curtain, protection for cable or fuel tube, flame retardant coating of high temperature metal compensator, and other industrial thermal insulation, heat preservation, fire resistance and protection.

Rope

Insulation of high temperature tube and container etc., cable insulation twine, the seal of coking furnace opening, the dilatation joint of cracking furnace brick wall, the seal of the doors of electric furnace and oven, the seal of the boiler and hot gas obturator, bind of flexible expansion joint.

Tape

Insulation for the industrial, insulation twine of the air duct etc., the flange coupling of screw bolt, thermal radiation shield, the curtain of high-temperature furnace.

Yarn

Materials for stitching up the fireproof cloth.

Packaging of our ceramic fiber insulation blanket:

1. Carton box outside and plastic bag inside

2. According to customer's requirements

3. We will do our best to avoid the goods damage and secure your goods in transportation.

The best Ceramic Fiber service provider

Provide high temperature solutions and professionals construction services for different fields for our customers.

Provide the most reasonable logistics for customers to save every penny.

Production of goods are finished, thoughtful provide products and packaging photos for our customers.
