Fire Clay Lightweight Insulating Castable Refractory Cement For Steel Making Industry

I'm Online Chat Now

Fire Clay Lightweight Insulating Castable Refractory Cement For Steel Making Industry

Fire Clay Lightweight Insulating Castable Refractory Cement For Steel Making Industry
Fire Clay Lightweight Insulating Castable Refractory Cement For Steel Making Industry Fire Clay Lightweight Insulating Castable Refractory Cement For Steel Making Industry Fire Clay Lightweight Insulating Castable Refractory Cement For Steel Making Industry Fire Clay Lightweight Insulating Castable Refractory Cement For Steel Making Industry Fire Clay Lightweight Insulating Castable Refractory Cement For Steel Making Industry

Large Image :  Fire Clay Lightweight Insulating Castable Refractory Cement For Steel Making Industry

Product Details:
Place of Origin: Jiangsu, China
Brand Name: weihang
Payment & Shipping Terms:
Minimum Order Quantity: 1000 Kilogram
Price: Negotiate price
Packaging Details: Export polywood
Supply Ability: 1000 Ton per Month
Detailed Product Description
Usage: Hot Blast Stove Max Service Temperature: 1600
Quality: Super Class MgO Content (%): 0.8-1.2%
Refractoriness (Degree): Common (1580°< Refractoriness< 1770°)
High Light:

lightweight castable refractory

,

high temperature castable refractory

Cheap Factory Price Insulation Fire Clay Castables Light Weight Refractory Cement Castable



Production Descriptions

    Refractory castables are used to replace refractory bricks in monolithic linings in all types of furnaces and kilns. They can be classified as follows: standard, medium cement content, low cement, ultra low cement, insulating castables, applied either by casting or by gunning.

    These castables can be made from different materials such as heavy chamottes, andalusites, bauxites, mullites, corundum, tabular alumina, silicon carbide, or light weight chamottes, perlite and vermiculite for insulation purposes. According to your processes and your conditions of use, we will be able to give you customized prescriptions and competitive quotations.

    Standard / Medium Cement castables with high alumina cement can be used within temperatures from 1300oC up to 1800oC. They have good thermal shocks, good mechanical and chemical resistances such as for abrasion, chemical corrosion and physical wear.

Process conditions, time available for the repairs, accessibility, qualified applicators / efficient equipments (gunning machine, shot crating pumps,..) and costs are the key factors that will allow you to decide between different techniques of applications and families of castables.



  ZYQJ-500 ZYQJ-600 ZYQJ-700M ZYQJ-700H ZYQJ-800M ZYQJ-800H

(Kg/m3)

Bulk density

450~550 550~650 650~750 650~750 750~850 750~850

(Mpa) Cold crushing

strength

110℃ 0.7 1.2 4.0 4.0 5.0 5.0
900℃ 0.7 1.2 4.0 4.0 5.0 5.0

(%)

Linear change on reheating

-0.8 -0.8 ±0.5 ±0.5 ±0.4 ±0.4

(W/m.k) Thermal

conductivity

350℃ 0.18 0.2 0.22   0.24
500℃ 0.2 0.22 0.24   0.26

(℃)

Max temperature

800 900 1000 1200 1100 1300





  ZYQJ-900 ZYQJ-1000 ZYQJ-1100M ZYQJ-1200H ZYQJ-1400M ZYQJ-1500H

(Kg/m3)

Bulk density

  950~1050 1050~1150 1150~1250 1350~1450 1450~1550

(Mpa)

Cold crushing strength

110℃ 7.0 8.0 9.0 13 26 30
900℃ 7.0 8.0 9.0 13 26 30

(%)

Linear change on

reheating

  ±0.3 ±0.3 ±0.2 ±0.2 ±0.2



(W/m.k) Thermal conductivity

350℃ 0.26 0.26 0.28 0.28 0.35 0.40
500℃ 0.28 0.28 0.30 0.30 0.37 0.45

(℃)

Max temperature

1200 1200 1300 1300 1300



Fire Clay Lightweight Insulating Castable Refractory Cement For Steel Making Industry 0

Application of high temperature castable refractory cement:

1. Iron&steel making industry:

Blast furnace,hot blast furnace(stove),pellet shaft furnace,hot metal ladle,steel ladle, tundish,heating furnace,soaking pit furnace,heat treatment furnace,refining furnace,reheating furnace,metal mixter furnace,annealing furnace, cupola furnace,electric arc furnace,induction furnace,AOD furnace,VOD furnace,etc thermal technology equipment.

2. Non-ferrous Metal industry:

Smelting furnace,refining furnace,reverberatory furnace,converter furnace.

3. Building materials industry:

Cement kiln,glass kiln,ceramic kiln,lime kilns,kiln car,tunnel kiln

4. Energy & Incineration:Coke oven,general boiler,power,generation,boiler,circulating fluidized bed boiler,electric furnace,carbon rosating furnace,waste incinerators.

5. Others:Petrochemical industry furnace.





R&D room
Fire Clay Lightweight Insulating Castable Refractory Cement For Steel Making Industry 1




Features and Advantages of refractory castable:
1. High refractoriness, High refractoriness under load.
2. High density, low porosity.
3. Good slag resistance and corrosion resistance.
4. High strength and wear resistance.
5. Good resistance to flake performance.
6. Good thermal shock stability.
7. Scouring resistance
8. Good hot strength.



Why choose us?
1. Our company has large production capacity(20000tons per year) ensure the fast production cycle after confirmed the order
2. Our company can produce and supply the products according to clients' requirements.To meet the refractory solutions, also can arrange technicians to customers' plant if needed
3. Our company can provide free sample for clients to test the quality.
4. Competitive Price.Make the products competitive in your market.
5. Strict Quality Control.Meet clients' quality requirement.
6. Professional Packing.Avoid damage and secure the goods in transportation
7. Your inquiry related to our products or prices will be replied in 24hours.
8. After sales service:We can provide 24 hours'consultation service.We are ready to answer our consultations at any time.
